Mobile Welding Fume Extractor/Dust Collector with Ce Certification
Basic Info.
| Model NO. | KSZ-3.0D |
| Motor Power | 3.0kw |
| Air Volume | 4000±100m³/H |
| Filter Area | 20m² |
| Description | Mobile Automatically Cleaning Welding Dust Collect |
| Transport Package | Wooden Case |
| Specification | 800*800*1633mm |
| Trademark | Kaisen |
| Origin | Shanghai, China |
| HS Code | 8421399090 |
| Production Capacity | 500sets/Month |
Product Description
Working Principle
The fume comes from the processing will be sucked into the extractor through the hood, first the fume passes the 1st layer preventer plate which will ramify the fume to avoid residual sparks enter into filter layer directly. Finally, the fume enters the second layer of HEPA filter cartridge for ultimate purification, and HEPA' s filtration efficiency can reach 99.9%. As the filtering precision of the main filter cartridge reaches the indoor emission standard, the filtered clean air can be directly discharged indoor via the vent in the bottom of the extractor.
Product introduction
This extractor can be automatically cleaned and manually cleaned, automatically cleaning is as following:
1. When air pressure difference reach 1500Pa between the interior and exterior of the filter cartridge, the system will implement interval rotation pulse blow cleaning.
2. When the fan stops working, the system will implement rotation pulse blow cleaning for three times.
Smart mobile welding fume extractor has two directional and two rotary polyurethane casters with brake device for easy moving and stationing. It is suitable for the purification of fume and dust generated in all kinds of welding, grinding and other places as well as for collecting rare metal particles and precious material.
Suction arm can be rotated by 360 °and can reach the position flexibly and easily by pulling the handle on the hood and position in the absence of external force. Depending on needs, 3m or 4m flexible suction arms are available. Suction arm uses high temperature resistant, flame retardant and wearable composite material, it will not crack after burning through by spark and has a longer usage life.
Main features
1. CE certification and EMC test report is approvable.
2. The voltage of 3x415V 50Hz & 3x3800V 50/60Hz is available.
3. Application for large fume occasion, it will make the arm acorrding to actual workshop conditions.
4. Large air flow, automatically cleaning, maintaining easy, two units arms to be more competitive price.
Technical parameters
No. | Item | Parameter |
| 1 | Fan type | centrifugal fan |
| 2 | Treatment of air flow | 2600±100 m3/h |
| 3 | Motor power | 3 kW |
| 4 | Power supply | 3×380 or 415V/50Hz |
| 5 | Filtration area | 20m2 |
| 6 | Number of cartridge filters | 2 pieces |
| 7 | Filter medium | PTFE coated filter element |
| 8 | Filtration efficiency | >99.9% |
| 9 | Solenoid valve | 2 pieces |
| 10 | Compressed air | 5~6 bar |
| 11 | Ash hopper volume | 15L |
| 12 | Noise | ≤74±5dB(A) |
| 13 | Weight | 266±10kg |
| 14 | Dimensions(excluding suction arm) | 800(L)×800(W)×1633(H)mm |
Company profile
Our products include mobile welding dust collector, wall mounted dust collector, high vacuum dust collector, laser & plasma cutting dust collector, grinding fume collector, 3D printer dust collector and system solution of fume disposal. Also,Kaisen had passed ISO9001, ISO14001 and OHSAS18001 approvals, most of products are CE certification.
